Trailer Stages 6m x 4m

Mobile stage trailer 6m x 4m

Stage 1, 6x4m (24SQM) 500 – 1000 People.

Even tho our 6m wide by 4m stage trailer unit is the smallest in our fleet it still has a very impressive performance area of 24 SQM with an internal roof height of 3.5metres with a stage floor height of 1m from the ground. Bringing the total height to 4.5metres from ground level. This option is most popular for small to medium one day events. The 6×4 stage can be used for outdoor festivals, Shows, Product Launches, Gala Days, Village Fetes and outdoor events.

Trailer Stages 6m x 4m specs,

Type of roof	standard 4.5 m high
Dimensions as a stage	Roof 6,0 m x 5,0 m – Floor 6,0 m x 4,0 m
Dimensions as a trailer	7,4 m x 2,45 m x 3,6 m
Permitted total weight	2500 kg
Stage floor area	24 m2
Height of stage floor	1,0 – 1,2 m
Stage floor	slip proof, weather proof
Roof capacity	30 kg – uniformly on front and back part of the roof (the end tube) 240 kg – uniformly on front and back part of the roof (the middle tube) 420 kg – uniformly on the middle part of the roof
Floor capacity	3,5 kN/m2 (ok.350 kg/m2)
Quadro system front pillars load capacity	50 kg
PA Towers load capacity	220KGS PER TOWER Maximum Load Rating.
Max. wind speed	Wind zone 1 – 3 excepting the 5 km wide coastal areas and the islands of the North Sea and the Baltic Sea:. max 17.8 m/s with the back and sides cover and max 30 m/s without cover
Max. thickness of snow on the roof	Mobile stages should be used only in periods in which there is no snow, unless the snow is effectively removed, e.g. by installing the appropriate heating devices
Canopy	PCV certified material (flame resistant)
Scrim	A203 (black)
Installation time	45 Mins (2 people)
